Encoder gateway installation
9
2
Encoder gateway installation
2.1
Settings inside the gateway
The encoder gateway addressing switches and bus termination
must be configured during commissioning of the device. This is
done by removing the back cover, i.e. screwing off the three
screws at the rear of the gateway.
Screws to remove
back cover
Figure 1
Placement of screws
