Chapter 2 Explore your monitor 2-5
Maximum resolutions
The display mode the monitor uses is controlled by the computer. Therefore, refer to your computer
documentation for details on how to change display modes.
The image size, position and shape might change when the display mode changes. This is normal
and the image can be readjusted using automatic image setup and the image controls.
Unlike CRT monitors, which require a high refresh rate to minimize flicker, LCD or Flat Panel
technology is inherently flicker-free.
Note: If your system has previously been used with a CRT monitor and is currently configured to a
display mode outside the range of this monitor, you may need to re-attach the CRT monitor
temporarily until you have re-configured the system; preferably to 5120x2160@ 60Hz, which is the
Native Resolution Display mode.
The display modes shown below have been optimized at the factory.
Table 2-5. Factory set display modes
Addressability Refresh rate
640x480 60Hz
720x400 70Hz
800x600 60Hz
1024x768 60Hz
1280x720 60Hz
1280x800 60Hz
1280x1024 60Hz
1440x900 60Hz
1600x900 60Hz
1680x1050 60Hz
1920x1080 60Hz
1920x1200 60Hz
2560x1080 60Hz
2560x1440 60Hz
3840x2160 60Hz *Note1
4096x2160 60Hz
5120x2160 30Hz
5120x2160 60Hz *Note 2
5120x2160 75Hz
*Note1: 3840x2160@ 60Hz is HDMI 2.0 native resolution.
*Note2: 5120x2160@ 60Hz is DisplayPort 1.4 (DP 1.4) native resolution.
Image rotation
Before rotating the monitor, you should set-up your computer to rotate the image. Rotating
the image may require special rotation software or you may find that your computer is
preloaded with video graphic drivers that allows image rotation. Check the Graphic
Properties setting on your computer to see if this feature is available. Try these steps to check
if image rotation is available on your computer.
1.Right-click on the desktop and click Properties.
2. Select the Settings tab and click Advanced.
3. If you have ATI, select the Rotation tab and set the preferred rotation. If you have nVidia,
click the nVidia tab, in the left-hand column select NV Rotate, and then select the preferred
rotation. If you have Intel, select the Intel graphics tab, click Graphic Properties, select the
Rotation tab, and then set the preferred rotation.
Check with the manufacturer of your computer to see if graphic drivers with image rotation
can be downloaded from their support website.
