192 - User's Manual
4-4. Graphical Layout and Screen Elements - Search
Search results
Calendar
1
5
2
Configured alarms 3
Trigger types 4
Playback button
Search conditions
The screen elements of the Playback window are described as follows:
Item Name Description
1 Search
conditions
The whole panel provides access to search conditions. You can select Devices,
time span, pre-configured alarms, or trigger types.
2 Calendar Shows when the possible time of occurrence of alarms.
3 Configured
alarms
Select the alarms you previously configured on the system.
4 Trigger types There are many trigger types including system event triggers, cyber attacks, DI /
DO, or the numerous VCA detection triggers.
5 Search results The results are displayed by Alarm name, Time of occurrence, Trigger source,
and the Trigger type.
