Chapter 6 Using Profile Utilities
232
// FirstEncodedLine(inclusive) = LastEncodedLine - Number of
lines per field
// Number of lines per field 240 - NTSC 4:2:0
// 256 - NTSC 4:2:2
// 288 - PAL 4:2:0
// 304 - PAL 4:2:2
// Also FirstEncodedLine - LastEncodedLine should be divis-
ible by 16.
//
// for example (NTSC 4:2:0) //12-00 18000000.0 420 1 1 5 2
0 21 261
// for example (NTSC 4:2:2) //12-00 18000000.0 422 1 1 5 2
0 5 261
// for example (PAL 4:2:0) //12-00 18000000.0 420 1 1 5 2
0 23 311
// for example (PAL 4:2:2) //12-00 18000000.0 422 1 1 5 2
0 7 311
// Video Resources
02-00,S // index 1 - DComponentVideo1InA
03-00 // index 2 - DComponentVideo1OutA
// Next line is for an MPEG Encoder
12-00 18000000 422 1 1 5 2 0 6 262 // index 3 - MpegEnc#1
01-02,CD // Default connect DComponentVideo1InA to
DComponentVideo1OutA (E to E) index1 to index2
01-03,CD // Default connect DComponentVideo1InA to
MpegEnc#1 (Record) index1 to index3
