Chapter 8 Using the Tool Box Editor
266 Profile Family
To subtract from a timecode, click inside a timecode indicator press – and the
timecode entry window appears. Enter the desired value in the form
00:00:00:00 and press Enter. The value is subtracted from the timecode. To
change the value of the timecode, click inside a timecode indicator press = and
the timecode entry window appears. Enter the desired value in the form
00:00:00:00 and press Enter. The value is changed to the desired timecode. If
an entry in the timecode entry window is out of bounds, it is ignored.
Figure 123. Timecode entry window
The E to E (Electronics to Electronics) button is to the right of the duration
timecode indicator. By default, E to E is off. If you click on this button, E to E
is activated. When E to E is off, the monitor shows the active timeline’s current
position. When it is on and no clips are playing or recording, the Profile
channel’s live video input bypasses the codec and is directly connected to the
outputs.
Figure 124. E to E button
Capturing a New Clip
Now you are ready to capture or record a new clip.
Figure 125. Record buttons
1. First, you need to enable video and/or audio for recording. To enable inputs
for recording, you can click on video or audio buttons. The buttons are lit
when activated.
Record Button
Video Enable Button
Audio Enable Button
