Appendix
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
145
Segment Byte Content Example/Comment
2
0 Configuration, fieldbus mod-
ule /
Integrated interface
Byte 0 contains the Hex code for a fieldbus module (in-
stalled on the left) or for inputs and outputs via the inte-
gr. interface:
Fieldbus module PNOZ mc / PNOZ mmc ... :30
Communication module PNOZ mmc1p: 02
Communication module PNOZ mmc2p: 01
Communication module PNOZ mmc1p plus fieldbus
module: 32
Communication module PNOZ mmc2p plus fieldbus
module: 31
No fieldbus module and no communication module: FF
Virtual inputs and outputs via integr. interface: 40
Communication module PNOZ mmc1p and virtual inputs
and outputs via integr. interface: 42
Communication module PNOZ mmc2p and virtual inputs
and outputs via integr. interface: 41
Additional input modules on the left:
PNOZml1p: See Table 1, Segment 8
1 Configuration, 1st expansion
module, right
Byte 1 ... 8 contains the Hex code for the expansion
modules on the right:
PNOZ mi1p: 08
PNOZ mi2p: 38
PNOZ mo1p: 18
PNOZ mo2p: 10
PNOZ mo3p: 30
PNOZ mo4p: 28
PNOZ mo5p: 48
PNOZ mc1p: 20
PNOZ ms3p: 68
PNOZ ms4p: 78
PNOZ ms1p/PNOZ ms2p: 88
PNOZ ms2p HTL: 58
PNOZ ms3p HTL: 64
PNOZsigma with one output: 11
PNOZsigma with two outputs: 22
No expansion module: 00
2 Configuration, 2nd expan-
sion module, right
3 Configuration, 3rd expansion
module, right
4 Configuration, 4th expansion
module, right
5 Configuration, 5th expansion
module, right
6 Configuration, 6th expansion
module, right
7 Configuration, 7th expansion
module, right
8 Configuration, 8th expansion
module right
9 Free
10 Free
11 Free
12 Free
