40
OPERATION
(Wall Mounted Controller ONLY) (cont.)
Control Panel (cont.)
Note:
1. The room temperature display range is from 16 °F (-9 °C) to 140 °F (60 °C).
When the display value is greater than 99 °F, it displays values of 00F (for 100
°F), 01F (for 101 °F) and 09F (for 109 °F).
2. When the wall mounted controller of other model is connected, the lowest set
point temperature is 60 °F (16 °C). The model name label is attached on the
wall mounted controller’s back cover.
11. COOL or FAN ONLY Illuminates to indicate COOL on or FAN ONLY on.
12. RUN or AUTO Illuminates to indicate fan mode set to RUN or
AUTO.
13. HI or LO Illuminates to indicate fan speed set to High or
Low.
14. Room temperature Illuminates temperature in either Fahrenheit (°F) or
Celsius (°C) (see Note).
15. Set temperature Illuminates temperature in either Fahrenheit (°F) or
Celsius (°C) in COOL mode. The temperature
range is from 55 °F (13 °C) to 95 °F (35 °C).
16. Day of the week and
time
Illuminates to indicate day of the week and time.
17. Clock symbol Illuminates to indicate program is running.
18. Key symbol Illuminates to indicate keypad locked.
19. CHECK Illuminates with self-diagnostic codes.
11
14
17
18
12
13
15
16
19
LCD DISPLAY
ILL00310-00
