60
TECHNICAL SPECIFICATIONS
Item Specifications
Electronic Features Control Wall Mounted Controller (Included)
Set Point
Temperature
Range
Max. 95 °F (35 °C)
Min. 55 °F (13 °C)
Electrical
Characteristics
Voltage Requirement Single-Phase, 208/230 V, 60 Hz
Operating
Voltage
Range
Max. 253 V
Min. 198 V
Recommended Fuse Size 20 A
MCA 13.5 A
MOP 23 A
Cooling Capacity and Power Consumption
Air: 80 °F (27 °C),
50 %RH/
Water (EWT/LWT):
85 °F /95 °F (29 °C/
35 °C)
Total Cooling Capacity
*1 29,400/29,400 Btu/h (8,640/8,640 W)
Sensible Cooling
Capacity
*1
20,400/20,800 Btu/h (6,000/6,120 W)
Power Consumption
*1 1.93 /1.99 kW
Current Consumption
*1 9.6 /8.9 A
Air: 75 °F (24 °C),
50%RH/
Water (EWT/LWT):
86 °F /95 °F (30 °C/
35 °C)
Total Cooling Capacity
*1 25,200/25,200 Btu/h (7,380/7,380 W)
Sensible Cooling
Capacity
*1
21,400/22,000 Btu/h (6,300/6,420 W)
Power Consumption
*1 1.95/2.00 kW
Current Consumption
*1 9.6/9.0 A
IEER 17.0
Compressor Type of Compressor Hermetic Swing Inverter
Evaporator Type of Evaporator Plate Fin
Type of Fan Centrifugal Fan
Air Flow High 1,000/1,060 CFM (1,700/1,800 m
3
/h)
Low 770/840 CFM (1,300/1,430 m
3
/h)
Max. External Static
Pressure
0.66 IWG (165 Pa)
Condenser Type Water Cooled, Coaxial Coil
Refrigerant Type R-410A
Amount 2.31 lb (1.05 kg)
Water Connection Water Inlet and Outlet (Unit
side)
3/4 in (19 mm) NPT Female
