Menu Operation 22
7 Menu Operation
1 MENU / BACK Button
2 HOME / LIVE Button
3 Jogwheel
4 SET Button
5 User Wheel
► Press the MENU / BACK button (1) on the MVF-2 to access the camera menu.
► Rotate the jogwheel (3) or the user wheel (5) to scroll up or down to select the desired menu entry:
Entries with a “>” at the end navigate to a sub menu. To navigate to a sub menu press the jogwheel
center or the SET button (4). To return to a higher menu level press the MENU / BACK button.
Entries with a value allow for direct editing. To edit a value press the jogwheel center or SET button,
then rotate the jogwheel or user wheel to select the desired value. Press the jogwheel center or
SET button to confirm the change or press CANCEL to discard.
Entries with a check box allow for direct activation/deactivation. Press the jogwheel center or SET
button to activate/deactivate the setting.
► To leave the menu press the HOME / LIVE button (2).
The jogwheel and the user wheel + SET button provide identical functionality.
7.1 HOME Screen
The HOME screen shows the most important camera settings and gives quick access to changing them
through the screen buttons.
1 FPS Sensor Frame Rate Settings
2 TC Timecode Settings
3 SHUTTER Settings
4 EI Exposure Index Settings
5 ND Filter Settings
6 WB White Balance Settings
7 Status Section
FPS (Sensor Frame Rate)
The FPS label shows the current sensor frame rate in frames per second. Press the FPS screen button
to adjust the sensor frame rate. The FPS label turns orange if the sensor frame rate does not match the
project frame rate.
