Main Parameters 36
9 Main Parameters
9.1 Project Settings
The project settings menu contains settings that should be configured at the beginning of each project
and can be found at MENU > Recording > Project Settings .
Project Rate
The project rate determines how many frames the timecode counts per second, and also determines
the frame rate at which clips are played back.
Changing the project frame rate will automatically change the sensor frame rate and the SDI frame
rates to the same frame rate. It is still possible to have different frame rates for these settings by
changing the sensor frame rate or the SDI frame rates individually.
► Select
MENU > Recording > Project Settings > Project Rate .
The following project rates are available:
Project Rate
23.976p
24p
25p
29.97p
30p
48p
50p
59.94p
60p
Scan Format
Progressive
Progressive
Progressive
Progressive
Progressive
Progressive
Progressive
Progressive
Progressive
Sensor Real-time Recording
23.976 fps
24 fps
25 fps
29.97 fps
30 fps
48 fps
50 fps
59.94 fps
60 fps
Next Reel Count
The next reel count sets the reel number assigned to the next new recording medium. The camera will
automatically increment the reel number each time a new recording medium is inserted, erased and
recorded on. If a previously used media is reloaded in the camera (comparable to a short end of a film
roll), it will keep its reel number and the camera will increment the reel count. If the media is loaded in
another camera, it keeps its name, but a new folder with the according camera ID and reel number is
created in the root folder of the media. It is possible, but usually not necessary, to manually change the
next reel number.
► Select
MENU > Recording > Project Settings > Next Reel Count .
► Set the desired next reel count between 0001 and 9999.
Camera Index
Each camera can be assigned a unique two character camera index so that you can identify the
individual camera unit (A, B, C etc.) in clip and reel names. For additional information please see "Clip
Naming Scheme", page 58 .
► Select MENU > Recording > Project Settings > Camera Index to set the camera index.
