Changing Various Settings
Changing Various Settings
■ Quick Access Toolbar/Ribbon
A menu appears when in the [Quick Access
Toolbar] is clicked.
Click [More commands] to add or remove the
commands appearing in the list of the [Quick
Access Toolbar].
Click [Show Below the Ribbon] to move the
[Quick Access Toolbar] below the Ribbon. To
return it to its original position, display the menu as
described above, and then click [Show Above the
Ribbon].
If a check mark appears beside [Minimize the
Ribbon], the Ribbon is minimized. When a tab is
clicked, the Ribbon appears. After a command is
selected, the Ribbon is minimized again. To restore
it to its original display, clear the check mark.
Example: With [Show Below the Ribbon] selected
and a check mark beside [Minimize the Ribbon]
■ Quick Access Toolbar commands
The first time this application is started up, the
following commands appear in the Quick Access
Toolbar (A).
Click , then select or unselect the check boxes
beside the commands to switch between displaying
and hiding them. When the check mark is cleared,
the command is hidden. Alternatively, changes to
the commands listed in the [Quick Access
Toolbar] can be specified in the [Options] dialog
box and all applied at the same time.
cc "Customizing Quick Access Toolbar" on
page 300
■ Import/Color/Sewing Attributes/
Text Attributes pane, Sewing
Order pane and Stitch Simulator
pane
Floating
Each tab or the entire pane can be undocked to
become a dialog box that can be moved around the
screen.
• Double-click the title bar of the pane, or tab.
• Right-click the pane or tab, and then click
[Floating].
• Drag a tab out of the pane.
Customizing the window
: New : Undo
: Open : Redo
: Save : Wizard
: Zoom in
