a. Pivot the tab
1
on the multi-function bracket outward until it stops. The PCIe card latch
2
is opened.
Lift the handle
4
on the rear of the chassis until it stops, and then pivot it as shown until it stops. The
PCIe card latch
3
is opened.
Figure 113. Opening PCIe card latches
b. If needed, remove the appropriate metal slot cover on the rear of the chassis.
c. If the PCIe card slot has a retaining latch, press the card retaining latch downward to disengage the
latch.
