12 EDIUS - User Guide
Timeline Window
Perform major editing works on the timeline window. Place clips (video, audio, still image, title, etc.) along the time axis.
(1) Mode bar These buttons are used to switch the editing modes.
Editing Modes 0 P54
(2) Sequence tab A sequence is a single timeline included in a project. A project can be com-
prised of multiple sequences.
Sequence 0 P65
(3) Time scale Indicate the scale for the time on the timeline.
(4) Time scale settings Change the display unit for time scale.
Time Scale Settings/Track Header 0 P13
(5) Track header Configure various settings including muting and locking each track, mapping
channels, synchronizing channels, etc. It can be used to add and delete
tracks.
Time Scale Settings/Track Header 0 P13
(6) Timeline Place clips in this area. It can also be used to add and delete tracks.
(7) Status bar View various status such as timeline playback, the number of offline clips,
editing mode, and background job process. Move the cursor over the mode
bar or timeline operation buttons to display the button names on the lower
left.
(8) Timeline cursor Indicate the playback position or edit position of the timeline.
(1) (2) (3)
(5)
(6)
(7)
(8)
(4)
