10 | LulzBot TAZ Pro S
3.3 Unscrew and save the four (4)
thumbscrews from the mounting
brackets.
3.4 Place the Y-axis assembly on
the frame with the LulzBot logo
on the front right corner of the
modular print bed. Line up the
four mounting brackets.
3.5 Slide the modular print bed
to the back and screw in the front
two thumbscrews until they are
finger tight. Slide the modular
print bed to the front and screw in
the back two thumbscrews until
they are finger tight.
