VIVOTEK
User's Manual - 349
© 2022 VIVOTEK INC. All Right Reserved
218
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
foldername string[128] 6/6 Path to store media.
* We support this parameter when the
version number (httpversion) is equal or
greater than 0312a.
action_cf_media NULL, 0~4,101 6/6 Index of the attached media.
101 means “Recording Notify”
* Only available when
"capability_supportsd" > 0
action_cf_datefolder
<Not support anymore>
<boolean> 6/6 Enable this to create folders by date,
time, and hour automatically.
* Only available when
"capability_supportsd" > 0
action_cf_backup <Boolean> 6/6 Enable or disable the function that send
media to SD card for backup if network is
disconnected.
* Only available when
"capability_supportsd" > 0
action_server_i<0~4>_en
able <boolean> 6/6 Enable or disable this server action.
action_server_i<0~4>_m
edia NULL, 0~4,101 6/6 Index of the attached media.
101 means "Recording Notify"
action_server_i<0~4>_da
tefolder
<Not support anymore>
<boolean> 6/6 Enable this to create folders by date,
time, and hour automatically.
action_goto_enable
<product dependent>
<boolean> 6/6 Enable/disable ptz goto preset position
on event triggered.
* Only available when
"capability_ptzenabled" > 0.
action_goto_name
<product dependent>
string[40] 6/6 Specify the preset name that ptz goto on
event triggered.
* Only available when
"capability_ptzenabled" > 0.
© 2022 VIVOTEK INC. All Right Reserved
219
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
action_goto_sync
<product dependent>
<boolean> 6/6 Capture media after moving to the
location.
* Only avaliable when the bit4 of
capability_ptzenabled is 1 and the bit7 of
capability_ptzenabled is 0, or
capability_camctrl_c0_zoommodule > 0
action_autotrack_enable
<product dependent>
<boolean> 6/6 Enable/disable auto tracking when an
event is triggerd.
* Only avaliable when the bit4 of
capability_ptzenabled is 1 and the bit7 of
capability_ptzenabled is 0
action_autotrack_name
<product dependent>
string[40] 6/6 Indicate the source name of smart
tracking advanced when an event is
triggered.
* Only avaliable when the bit4 of
capability_ptzenabled is 1 and the bit7 of
capability_ptzenabled is 0, and the
camera supports “Smart Tracking
Advanced” feature. (Please refer to PTZ
Control API for more details)
* We support this parameter when the
version number (httpversion) is equal or
greater than 0317d.
action_tour_enable
<product dependent>
<boolean> 6/6 Enable/disable auto tour function when
an event is triggered.
* Only avaliable when the bit4 of
capability_ptzenabled is 1 and the bit7 of
capability_ptzenabled is 0
action_tour_name
<product dependent>
string[40] 6/6 Indicate the source name of auto tour
when an event is triggered.
* Only avaliable when the bit4 of
capability_ptzenabled is 1 and the bit7 of
capability_ptzenabled is 0
