Page 128
VIVOTEK
128 - User's Manual
■
Event name: Enter a name for the event setting.
■
Enable this event: Select this checkbox to enable the event setting.
■
Priority: Select the relative importance of this event (High, Normal, or Low). Events with a higher
priority setting will be executed first.
■
Detect next motion detection or digital input after seconds: Enter the duration in seconds to pause
motion detection after a motion is detected. This prevents too many events to be triggered within a
short time.
Follow the steps 1~3 to arrange the three elements -- Schedule, Trigger, and Action to set an event. A
total of 3 event settings can be configured.
1. Schedule
Specify the period for the event. Please select the days of the week and the time in a day (in 24-hr time
format) to specify when will the event-triggering conditions take effect.
2. Trigger
This is the cause or stimulus which defines what will trigger the event. The trigger source can be config
-
ured to use the Network Camera’s built-in motion detection mechanism or external digital inputs.
There are several choices of trigger sources as shown below. Select each item to display its related
options.
■ Video motion detection
This option makes use of the built-in motion detection mechanism as a trigger source. To enable this
function, you need to configure a Motion Detection Window first. For more information,
Motion Detection on page 141 for details.
■ Periodically
This option allows the Network Camera to trigger periodically for every other defined minute. Up to 999
minutes are allowed.
■ Digital input
This option allows the Network Camera to use an external digital input device or sensor as a trigger
source. Depending on your application, there are many choices with digital input devices on the market
which help detect changes in temperature, vibration, sound, light, etc.
■ System boot
This option triggers the Network Camera when the power to the Network Camera is disconnected.
■ Recording notify
This option allows the Network Camera to trigger when the recording disk is full or when recording
starts to overwrite older data.
