Vivotek FE9380-HV 5MP Outdoor Network Fisheye Dome Camera with Night Vision - Manual (Page 287)

VIVOTEK
User's Manual - 287
weekday 0~127 6/6 Indicate which weekday is scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on Friday and
Sunday, set weekday as 66.
begintime hh:mm 6/6 Begin time of the weekly schedule.
endtime hh:mm 6/6 End time of the weekly schedule.
(00:00 ~ 24:00 sets schedule as always on)
lowlightcondition
<product dependent> 0, 1 6/6 Switch on white light LED in low light condition
0 => Do action at all times
1 => Do action in low-light conditions
action_do_i<0~(ndo-1)>_e
nable <boolean> 6/6 Enable or disable trigger digital output.
* Only available when "capability_ndo" > 0
action_do_i<0~(ndo-1)>_
duration 1~999 6/6 Duration of the digital output trigger in seconds.
* Only available when "capability_ndo" > 0
action_cf_enable <Boolean> 6/6 Enable or disable sending media to SD card.
action_cf_folder string[128] 6/6 Path to store media.
action_cf_media NULL, 0~4,101 6/6 Index of the attached media.
101 means “Recording Notify”
action_cf_datefolder <boolean> 6/6 Enable this to create folders by date, time, and
hour automatically.
action_cf_backup <Boolean> 6/6 Enable or disable the function that send media to
SD card for backup if network is disconnected.
action_server_i<0~4>_ena
ble <boolean> 6/6 Enable or disable this server action.
action_server_i<0~4>_me
dia NULL, 0~4,101 6/6 Index of the attached media.
101 means “Recording Notify”
action_server_i<0~4>_dat
efolder <boolean> 6/6 Enable this to create folders by date, time, and
hour automatically.
action_goto_enable
<product dependent> <boolean> 6/6 Enable/disable ptz goto preset position on event
triggered.
* Only available when capability_ptzenabled >
0.
