VIVOTEK
96 - User's Manual
Network > Streaming protocols
HTTP streaming
To utilize HTTP authentication, make sure that your have set a password for the Network Camera first;
please refer to Security > User account on page 109 for details.
Authentication: Depending on your network security requirements, the Network Camera provides two
types of security settings for an HTTP transaction: basic and digest.
If
basic
authentication is selected, the password is sent in plain text format and there can be potential
risks of being intercepted. If
digest
authentication is selected, user credentials are encrypted using MD5
algorithm and thus provide better protection against unauthorized access.
HTTP port / Secondary HTTP port: By default, the HTTP port is set to
80
and the secondary HTTP port is
set to
8080
. They can also be assigned to another port number between 1025 and 65535. If the ports are
incorrectly assigned, the following warning messages will be displayed:
To access the Network Camera on the LAN, both the HTTP port and secondary HTTP port can be used
to access the Network Camera. For example, when the HTTP port is set to 80 and the secondary HTTP
port is set to 8080, refer to the list below for the Network Camera’s IP address.
Access name for Channel # and stream #: This Network camera supports multiple streams
simultaneously.
The access name is used to differentiate the streaming source. Users can click
Media >
Video > Stream settings
to set up the video quality of linked streams. For more information about how
to set up the video quality, please refer to Stream settings on page 79.
When using Mozilla Firefox or Netscape to access the Network Camera and the video mode is set to
JPEG
, users will receive video comprised of continuous JPEG images. This technology, known as “server
push”, allows the Network Camera to feed live pictures to Mozilla Firefox and Netscape.
On the LAN
http://192.168.4.160 or
http://192.168.4.160:8080
