Vivotek FE9380-HV 5MP Outdoor Network Fisheye Dome Camera with Night Vision - Manual (Page 288)

VIVOTEK
288 - User's Manual
action_goto_name
<product dependent> string[40] 6/6 Specify the preset name that ptz goto on event
triggered.
* Only available when capability_ptzenabled >
0.
action_goto_sync
<product dependent> <boolean> 6/6 Capture media after moving to the location.
* Only avaliable when the bit4 of
capability_ptzenable is 1 and the bit7 of
capability_ptzenable is 0
action_autotrack_enable
<product dependent> <boolean> 6/6 Enable/disable auto tracking on event triggerd.
* Only avaliable when the bit4 of
capability_ptzenable is 1 and the bit7 of
capability_ptzenable is 0
7.28 Server setting for event action
Group: server_i <0~4>
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
name string[40] 6/6 Identification of this entry
type email,
ftp,
http,
ns
6/6 Indicate the server type:
“email” = email server
“ftp” = FTP server
“http” = HTTP server
“ns” = network storage
http_url string[128] 6/6 URL of the HTTP server to upload.
http_username string[64] 6/6 Username to log in to the server.
http_passwd string[64] 6/6 Password of the user.
ftp_address string[128] 6/6 FTP server address.
ftp_username string[64] 6/6 Username to log in to the server.
ftp_passwd string[64] 6/6 Password of the user.
ftp_port 0~65535 6/6 Port to connect to the server.
ftp_location string[128] 6/6 Location to upload or store the media.
ftp_passive <boolean> 6/6 Enable or disable passive mode.
0 = disable passive mode
1 = enable passive mode
email_address string[128] 6/6 Email server address.
email_sslmode <boolean> 6/6 Enable support SSL.
