VIVOTEK
142 - User's Manual
A green bar indicates that even though motions have been detected, the event has not been triggered
because the image variations still fall under the preset threshold.
If you want to configure other motion detection settings for day/night/schedule mode (e.g., for a different
lighting condition during a specific period of time), please click
Profile mode
to open the Motion
Detection Profile Settings page as shown below. Another three motion detection windows can be
configured on this page.
Larger than the
min. item size
Photos or videos can be captured instantly and configured to be sent to a remote server (via an Email or
FTP server).
For more information on how to configure an event setting, please refer to Event settings on
Please follow the steps beolw to set up a profile:
1.
Create a new motion detection window, and configure the minimum item size.
2. Click the
Profile mode
tab.
3. Select the applicable Schedule mode. Please manually enter a time range.
4. Click
Save
to enable the settings and click
Close
to exit the page.
