Vivotek FE9380-HV 5MP Outdoor Network Fisheye Dome Camera with Night Vision - Manual (Page 298)

VIVOTEK
298 - User's Manual
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
patrolseq string[120] 1/4 The patrol sequence of ePTZ. All the patrol
position indexes will be separated by ","
patroldwelling string[160] 1/4 The dwelling time (unit: second) of each patrol
point, separated by “,”.
preset_i<0~19>_name string[40] 1/4 Name of ePTZ preset.
* Only available when "capability_fisheye" is 1
1/7 Name of ePTZ preset.
(It should be set by ePreset.cgi rather than by
setparam.cgi.)
preset_i<0~19>_pos <W,H>
<product dependent>
1/4 Left-top corner coordinate of the preset.
* Only available when "capability_fisheye" is 1
1/7 Left-top corner coordinate of the preset.
(It should be set by ePreset.cgi rather than by
setparam.cgi.)
preset_i<0~19>_size <WxH>
<product dependent>
1/4 Width and height of the preset.
* Only available when "capability_fisheye" is 1
1/7 Width and height of the preset.
(It should be set by ePreset.cgi rather than by
setparam.cgi.)
7.35 Focus Window setting
Group: focuswindow_c<0~(n-1)> for n channel products
n denotes the value of "capability_nvideoin".
(capability_image_c<0~(n-1)>_remotefocus=1 or capability_image_c<0~(n-1)>_remotefocus=4)
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
win_i0_enable <boolean> 4/4 Enable or disable the window.
win_i0_home <W,H>
<product dependent>
4/4 Left-top corner coordinate of the window.
* If the minimal window size is 192x144, then
the "win_i0_home"=(0~resolution_W-192,
0~resolution_H-144), which the resolution is
the value in current stream.
win_i0_size <WxH>
<product dependent>
4/4 Width and height of the window.
* The minimal window size is 192x144
