VIVOTEK
296 - User's Manual
7.33 Region of interest
Group: roi_c<0~(n-1)> for n channel product. (capability.eptz > 0)
m denotes the value of "capability_nmediastream".
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
s<0~(m-2)>_home <W,H>
<product dependent>
1/6 ROI left-top corner coordinate.* If the minimal
window size is 64x64, then the
"win_i0_home"=(0~resolution_W-64,
0~resolution_H-64), which the resolution is the
value in current stream.
s<0~(m-2)>_size <WxH>
<product dependent>
1/6 ROI width and height. The width value must be
multiples of 16 and the height value must be
multiples of 8* The minimal window size is
64x64
s<m-1>_home <W,H>
<product dependent>
1/7 ROI left-top corner coordinate.* If the minimal
window size is 64x64, then the
"win_i0_home"=(0~resolution_W-64,
0~resolution_H-64), which the resolution is the
value in current stream.
s<m-1>_size <WxH>
<product dependent>
1/7 ROI width and height. The width value must be
multiples of 16 and the height value must be
multiples of 8* The minimal window size is
64x64
