34 Zodiak — User Manual
Section 1 — System Overview
System Control
Zodiak system control is designed for flexibility and simplicity. Ethernet,
serial, parallel, and USB are used for system component interconnections.
Tally and GPI control are available. Windows 2000 drives the Menu panel
touch screen. An overview of Zodiak system control is shown in
Figure 9 .
Figure 9. Zodiak System Control
Menu LAN
USB
Optional Keyboard
Optional Mouse
Menu Panel
Zip Drive
Optional
Future Satellite
Panels (1-2)
NOTE: Main Panel, Menu LAN, Panel LAN 10Base-T or 100Base-T Ethernnet
Main Panel
Point to Point Serial
RS-422/Serial Async
8096_00_19_r3
Main Control Surface
Floppy
Drive
Control Panel Processor
System Processor
Button Knob Control (Serial)
Touch Screen Control (Serial)
8 GPI In
8 GPI Out
4 Serial
Tally (Relay)
2 CPL
Video Processor Frame
Control System
Hard
Drive
Floppy
Drive
CD-ROM
Panel LAN
Control Line
Control Surface Boundary
Serial
4 GPI In
4 GPI Out
