7-42
Instruction Set of the I/O Processor
Figure 7.26 Write Cycle, Slow Memory (
≥
64 Kbyte)
MAD
(Driven by LSI53C875)
MAS2/
(Driven by LSI53C875)
MAS1/
(Driven by LSI53C875)
MAS0/
(Driven by LSI53C875)
MCE/
(Driven by LSI53C875)
MOE/
(Driven by LSI53C875)
CLK
Middle Address
1
2
3
4
5
6
7
8
9
MWE/
(Driven by LSI53C875)
High Order Address
Low order
Address
t
12
t
11
t
13
t
24s
t
25
t
20
t
23
Valid Write
Data
