Dataman-40Pro
Introduction
Dataman-40Pro is the next member of the new generation of
Windows 95/98/Me/NT/2000/XP based universal
programmers. This programmer is built to meet the demands
of development labs and field engineers for a fast, reliable, and
versatile programming.
Dataman-40Pro is a small, fast and powerful programmer.
Using the built-in, in-circuit serial programming (ISP)
connector, the programmer is capable of in-circuit
programming.
Dataman-40Pro is competitively priced, with excellent
hardware design for reliable programming.
Dataman-40Pro offers very fast programming due to high-
speed FPGA driven hardware and USB 2.0 full speed port. It is
surely faster than competitors in this category.
Dataman-40Pro interfaces with the IBM PC Pentium
compatible or higher, portable or desktop personal computers
through USB port. Therefore you can take the programmer and
move it to another PC without assembly/disassembly of the
PC.
Dataman-40Pro has 40 powerful TTL pindrivers to provide
H/L/pull_up/pull_down and read capability for each pin in the
socket. Advanced pindrivers incorporate high-quality high-
speed circuitry to deliver signals without overshoot or ground
bounce for all supported devices. Pin drivers operate down to
1.8V so you'll be ready to program the full range of today's
advanced low-voltage devices.
The programmer performs a device insertion test (wrong
device position in socket) and contact check (poor contact pin-
to-socket) before it programs each device. These capabilities,
supported by signature-byte check, help prevent chip damage
due to operator error.
The programmer's hardware offers enough resources for a
detailed selftest. The control program is able to check
pindrivers, voltages levels, and communication between the
programmer and the PC.
Dataman-40Pro programmer performs a device verification at the
upper and lower limits of the supply voltage, which, improves
programming yield, and guarantees long data retention.
