Quick Start Guide
Kiaro! 200 User Guide 13
Installing the Printer Driver (USB)
Use the following instructions to install the printer via USB 2.0 on Windows XP,
Windows Vista, Windows 7, or Windows 8.
Note: When the Windows logo testing, publisher verification, or digital signing warning
messages appear, choose to continue the installation. These messages indicate that the driver has
not been “logo tested” by Microsoft. However, it has been tested thoroughly by QuickLabel
Systems, and will not cause any of the problems listed in these messages.
1 Ensure the Kiaro! 200 is powered on but not connected to your computer via the
USB cable.
2 Power on your computer and insert the Kiaro! 200 Installer CD in the CD drive.
The Installer CD wizard will open. Choose
Next .
Note: If the autorun program does not start automatically, use Windows Explorer to
launch the “Setup.exe” file located in the root level of the CD.
3 Use the driver installation wizard to install the driver. Refer to the following
information during this process.
• Choose the USB connection method when prompted.
• Select an installation location for the Kiaro! 200 Maintenance Utility when
prompted.
Choose Finish in the installation wizard after successfully installing the Kiaro! 200
Maintenance Utility and driver.
4 Connect the smaller end of the USB cable to the Kiaro! 200 USB type B port.
Connect the larger end of the USB cable to an available USB 2.0 port on your
computer.
