Chapter 10 Using TimeDelay
292
Profile Family
ty = type (a four-bit bitmap with the following bit
assignments)
bit 0:
0 = Cancel.
1 = Perform operation.
bit 1:
0 = Set timecode for just this panel.
1 = Set timecode for all panels.
bit2:
0 = Timecode value is absolute.
1 = Timecode value is relative.
bit3:
0 = Timecode value is positive.
1 = Timecode value is negative (only valid for
relative timecodes).
ff ss mm hh = timecode
cs = checksum
Jog
Jog panel #fields
Positions the current clip #fields forward (if positive) or backward (if negative)
from the current position. Valid for censor channel only; ignored for record and
playback channels.
UI equivalent:
Manipulating the jog slider in the censor channel.
Packet format:
21 39 pa nf cs
where:
pa = panel
nf = #fields (signed one-byte numeric value)
cs = checksum
JoinBoth
JoinBoth panel
Combines the selected segment with both the previous and next segments in the
list of segments. Valid for censor channel only; ignored for record and playback
channels.
UI equivalent:
Clicking on the
Join Both
button.
Packet format:
41 42 pa cs
where:
pa = panel
cs = checksum
