Vivotek SD9161-H-v2 2MP PTZ Network Dome Camera - Manual (Page 343)

VIVOTEK
User's Manual - 343
© 2022 VIVOTEK INC. All Right Reserved
192
NAME VALUE SECURITY
(get/set) DESCRIPTION
dependent> name":"Policy":"Description"
"Policy" can be categorized into
following groups:
- (disabled) : UI turns grey and users
can't select it.
- (unchanged) : UI keeps the status as
before and
user can't change it.
- (hidden) : UI is hidden.
- (fixed) : UI is fixed to one selection or
value.
- (ranged) : UI is fixed to multiple
selections or values.
- (enabled) : UI is checked.
- (notsupport) : the affected function
is not available.
"Affect API name" can be described in
hierarchy, such as
"exposurewin.mode.blc: disabled:"
which means blc exposure window is
disabled. API name can be one word
as well, such as
"exposurelevel:fixed:6" which means
exposurelevel is fixed to level 6.
"Description" can be a nonnegative
integer or string or NULL.
"-" means no feature is affected.
* Only available when "railtrack" is
listed in
"capability_image_c<0~(n-1)>_scene
mode_supporttype" and
"capability_image_c<0~(n-1)>_scene
mode_support" is 1.
© 2022 VIVOTEK INC. All Right Reserved
193
NAME VALUE SECURITY
(get/set) DESCRIPTION
wbmode auto,
panorama,
manual,
rbgain,
widerange,
outdoor,indoor,
sodiumauto,
-
<product
dependent>
0/7 Available white balance mode.
"-" means white balance is not
supported.
iristype piris,
dciris,
- 0/7 Indicate iris type.
"piris": P-Iris
"dciris": DC-Iris
"-": No Iris control support
* Note: For some cameras, this value
may be varied depending on mounted
lens.
sensortype rawsensor,
smartsensor,
thermalsensor,
- 0/7 Indicate sensor type.
"rawsensor" : Raw sensor
"smartsensor" : Smart sensor
"thermalsensor" : Thermal sensor
"-" : N/A
* We support this parameter when
the version number (httpversion) is
equal or greater than 0302a.
exposure_mode 0,1 0/7 0: Non-support exposure control.
1: Support exposure control.
exposure_modetype auto,
shutterpriority,
irispriority,
manual
<product
dependent>
0/7 Available mode of exposure setting.
* Only available when
"capability_image_c<0~(n-1)>_
exposure_mode" is 1.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0302a.
exposure_rangetype onevalue,
twovalues 0/7 Support interface of exposure range.
"onevalue" : The parameter is a
