VIVOTEK
User's Manual - 97
Primary DNS : The primary domain name server that translates host names into IP addresses.
Secondary DNS : Secondary domain name server that backs up the Primary DNS.
Primary WINS server : The primary WINS server that maintains the database of computer names and IP
addresses.
Secondary WINS server : The secondary WINS server that maintains the database of computer names
and IP addresses.
Enable UPnP presentation : Select this option to enable UPnP TM presentation for your Network Camera
so that whenever a Network Camera is presented to the LAN, the shortcuts to connected Network
Cameras will be listed in My Network Places. You can click the shortcut to link to the web browser.
Currently, UPnP TM is supported by Windows XP or later. Note that to utilize this feature, please make
sure the UPnP TM component is installed on your computer.
Enable UPnP port forwarding : To access the Network Camera from the Internet, select this option to
allow the Network Camera to open ports automatically on the router so that video streams can be sent
out from a LAN. To utilize of this feature, make sure that your router supports UPnP TM and it is activated.
PPPoE (Point-to-point over Ethernet)
Select this option to configure your Network Camera to make it accessible from anywhere as long as
there is an Internet connection. Note that to utilize this feature, it requires an account provided by your
ISP.
Follow the steps below to acquire your Network Camera’s public IP address.
1. Set up the Network Camera on the LAN.
2. Go to Configuration > Event > Event settings > Add server (please refer to Add server on page 150) to
add a new email or FTP server.
3. Go to Configuration > Event > Event settings > Add media (please refer to Add media on page 138).
Select System log so that you will receive the system log in TXT file format which contains the
Network Camera’s public IP address in your email or on the FTP server.
4. Go to Configuration > Network > General settings > Network type. Select PPPoE and enter the user
name and password provided by your ISP. Click Save to enable the setting.
5. The Network Camera will reboot.
6. Disconnect the power to the Network Camera; remove it from the LAN environment.
Mega-pixel Network Camera (192.168.5.151)
