Page 115
IQOYA SERV/LINK user manual
115
9.2.3.2 Edit a call profile
To edit an existing call profile, click the icon
on the left of this latter.
The edit page is identical to the add page described in the previous paragraph.
9.2.3.3 Delete call profiles
To delete a call profile, click the icon
on the left of this latter.
To delete several call profiles at the same time, check the box of the call profiles you want to delete then click
“Delete” item in the “For selected Profiles(s)” menu at the top of the page:
●
+50% bandwidth, recovery 2, 1 stream (audio)
●
+100% bandwidth, recovery 3, 2 streams (audio + FEC)
●
+100% bandwidth, recovery 4, 2 streams (audio + FEC)
●
+50% bandwidth, recovery 1/2, 2 streams (audio + FEC)
●
+33% bandwidth, recovery 1/3, 2 streams (audio + FEC)
●
+25% bandwidth, recovery 1/4, 2 streams (audio + FEC)
●
+20% bandwidth, recovery 1/5, 2 streams (audio + FEC)
●
+10% bandwidth, recovery 1/10, 2 streams (audio + FEC)
'recovery N' means that up to N consecutive lost IP packets can be
reconstructed thanks to the FEC scheme, 'recovery 1/N' means one
lost IP packet out of N consecutive packets can be reconstructed
thanks to the FEC scheme.
Advanced parameters:
Audio stream payload type
Read/Write
Visible only if “Asymmetric settings” is checked.
Payload type of the audio stream sent by the remote party. It’s an
integer between 0 and 127.
Packet size (ms)
Read/Write
Visible only if “Asymmetric settings” is checked.
Defines the size in ms of the audio packets sent by the remote party or
0 not to negotiate the packet size.
FEC stream payload type
Read/Write
Visible only if “Asymmetric settings” is checked.
Payload type of the FEC stream sent by the remote party. It’s an
integer between 0 and 127.
