IQOYA SERV/LINK user manual
● Mono analog input signals 1 to 8 must be connected to inputs 1 to 8 of the breakout cable connected to
“Audio I/O port 1”.
● Stereo AES/EBU input signals 1 to 4 must be connected to AES/EBU inputs 1 to 4 of the breakout cable
connected to“Audio I/O port 1”
● Mono analog input signals 9 to 16 must be connected to inputs 1 to 8 of the breakout cable connected to
“Audio I/O port 2”
● Stereo AES/EBU input signals 5 to 8 must be connected to AES/EBU inputs 1 to 4 of the breakout cable
connected to“Audio I/O port 2”
● External synchro signal (AES clock, WordClock, Blackburst video reference) must be connected to the
corresponding synchro connector of the cable connected to “Audio I/O port 1”.
In case your IQOYA SERV/LINK features a MADI connection, connect the MADI input fiber to MADI IN connector,
and connect the MADI output fiber to MADI OUT connector.
Connect the WordClock signal to the WordClock input BNC connector.
5.3 Connecting IQOYA SERV/LINK to the network
We recommend that the first connection to the IQOYA codec is done on a LAN. The default IP addresses of
IQOYA SERV/LINK Eth ports are:
● Eth0: 192.168.0.100
● Eth1: 192.168.1.100
In case you do not know the IP addresses of the IQOYA SERV/LINK unit you want to connect to, you can read its
IP addresses from the front panel (see paragraph “LCD display and keypad”).
Make sure all other devices connected to this LAN are in the same subnet and have different IP addresses (this
includes the PC from which you will connect to the IQOYA codec to configure).
WARNING: Eth0 and Eth1 must not be configured on the same subnet!
5.4 Powering up IQOYA SERV/LINK
It is recommended to establish all connections before powering the device up.
IQOYA SERV/LINK features two hot swappable redundant power supply units. It is recommended to connect the
23
Warning: In case you use an IQOYA SERV/LINK 24241 or 32321 (which are AES/EBU only versions), the
Word Clock output from “Audio I/O Port 1” must be connected to the Word Clock input of “Audio I/O
Port 2”.
