Vivotek S Series IZ9361-EH 1080p Outdoor Network Bullet Camera with Heater - Manual (Page 331)

VIVOTEK
User's Manual - 331
© 2020 VIVOTEK INC. All Right Reserved
176
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
minresolution A list of <Integer> 0/7 Represent supported minimum
resolution of each stream in current
video mode.
* The element number is defined as
"capability_nmediastream".
* We support this parameter when the
version number (httpversion) is equal or
greater than 0304b.
maxframerate A list of <Positive
Integer> 0/7 Indicates frame rate that the video
source outputs in this video mode.
* One to one mapping to the resolution
in "resolution".
* The element number is defined as
"nresolution" in this group.
* This parameter records the frame rate
when
"videoin_c<0~(n-1)>_cmosfreq"=60 or
"videoin_c<0~(n-1)>_modulation"=ntsc
maxfps_mjpeg A list of <Positive
Integer> and "-" 0/7 Maximum fps which the device can
encoded with MJPEG on resolutions in
this video mode.
"-" means not support.
* One to one mapping to the resolution
in "resolution".
* The element number is defined as
"nresolution" in this group.
* This parameter records the frame rate
when
"videoin_c<0~(n-1)>_cmosfreq"=60 or
"videoin_c<0~(n-1)>_modulation"=ntsc
* Only available when 'mjpeg' is listed in
"capability_videoin_codec".
© 2020 VIVOTEK INC. All Right Reserved
177
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
maxfps_h264 A list of <Positive
Integer> and "-" 0/7 Maximum fps which the device can
encoded with H.264 on resolutions in this
video mode.
"-" means not support.
* One to one mapping to the resolution
in "resolution".
* The element number is defined as
"nresolution" in this group.
* This parameter records the frame rate
when
"videoin_c<0~(n-1)>_cmosfreq"=60 or
"videoin_c<0~(n-1)>_modulation"=ntsc
* Only available when 'h264' is listed in
"capability_videoin_codec".
maxfps_h265 A list of <Positive
Integer> and "-" 0/7 Maximum fps which the device can
encoded with H.265 on resolutions in this
video mode.
"-" means not support.
* One to one mapping to the resolution
in "resolution".
* The element number is defined as
"nresolution" in this group.
* This parameter records the frame rate
when
"videoin_c<0~(n-1)>_cmosfreq"=60 or
"videoin_c<0~(n-1)>_modulation"=ntsc
* Only available when 'h265' is listed in
"capability_videoin_codec".
description <string[128]> 0/7 Description about this mode.
7.27.9 Capability for Image
Group: capability_image_c<0~(n-1)> n denotes the value of "capability_nvideoin"
NAME VALUE SECURITY
(get/set) DESCRIPTION
basicsetting 0, <positive
integer> 0/7 A 32-bits integer, each bit can be set
separately as follows:
