VIVOTEK

User's Manual - 335

© 2020 VIVOTEK INC. All Right Reserved

180

NAME

VALUE

SECURITY
(get/set)

DESCRIPTION

* When "wdrpro"=0, this value must
be "-"

wdrpro_description

<string>

0/7

Description about WDR Pro mode.
* Only available when
"capability_image_c<0~(n-1)>_wdrpro
_mode" > 0

wdrc_mode

0, 1

0/7

0: Non-support WDR Enhanced
1: Support WDR Enhanced

wdrc_supportlevel

0, <positive
integer>

0/7

Indicate the support strength level of
WDR Enhanced.

wdrc_affect

-,
gammacurve:disabl
ed:,
<x>: nonnegative
integer

<product
dependent>

0/7

When WDR Enhanced is enabled,
some features may become
malfunction or be forced to a given
value. The affected functions are list
here.
The format is "Affect API
name":"Policy":"Description"
"Policy" can be categorized into
following groups:
- (disabled) : UI turns grey and users
can't select it.
- (unchanged) : UI keeps the status as
before and user can't change it.
- (hidden) : UI is hidden.
- (fixed) : UI is fixed to one selection or
value.
- (ranged) : UI is fixed to multiple
selections or values.
- (enabled) : UI is checked.
- (notsupport) : the affected function
is not available.
"Affect API name" can be described in
hierarchy, such as
"exposurewin.mode.blc:disabled:"
which means blc exposure window is
disabled. API name can be one word

© 2020 VIVOTEK INC. All Right Reserved

181

NAME

VALUE

SECURITY
(get/set)

DESCRIPTION

as well, such as
"exposurelevel:fixed:6" which means
exposurelevel is fixed to level 6.
"Description" can be a nonnegative
integer or string or NULL.
For example:
"exposurelevel:fixed:6/8/12" which
means exposurelevel is fixed to level
6, level 8 and level 12.
"-" means no feature is affected.
* When "wdrc"=0, this value must be
"-"

dnr

0,1

0/7

0: Non-support 3D digital noise
reduction
1: Support 3D digital noise reduction

dnrstrength

<positive integer>

0/7

Indicate the support strength level of
3D digital noise reduction.
* Only available when
"capability_image_c<0~(n-1)>_dnr" >
0.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0306d.

dnrtype

2d,3d

0/7

Description about DNR type.
* Only available when
"capability_image_c<0~(n-1)>_dnr" >
0.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0308a.

eis

0,1

0/7

0: Non-support electronic image
stabilizer
1: Support electronic image stabilizer

is_mode

eis,
dis,
-

0/7

Indicate the image stabilizer mode.

"eis"

: electronic image stabilizer

"dis"

: digital image stabilizer
