Vivotek S Series IZ9361-EH 1080p Outdoor Network Bullet Camera with Heater - Manual (Page 355)

VIVOTEK
User's Manual - 355
© 2020 VIVOTEK INC. All Right Reserved
200
NAME VALUE SECURITY
(get/set) DESCRIPTION
1: Support low light mode
focusassist 0,1 0/7 0: Non-support focus assist
1: Support focus assist
remotefocus 0,<positive
integer> 0/7 An 4-bit integer, which indicates the
supportive application of remotefocus
in this channel.
If the value of this parameter is larger
than 0, it means that the camera
supports remotefocus function in this
channel.
bit 0 => Indicate whether to support
both zoom and focus function.
bit 1 => Only support zoom function.
bit 2 => Only support focus
function.
bit 3 => Currently, this is a reserved
bit, and the default value is 0.
focuswindomain qvga, px, std, - 0/7 The domain to set a focus window.
"qvga" : a 320x240 range to represent
the whole image.
"px" : Locate a window in the image
with pixels.
"std" : A normalized 0~9999 range.
"-" : Not supported.
focuswindow_nwindo
w 0,<positive
integer> 0/7 Number of focus window
focuswindow_range <leftrange,rightran
ge,toprange,lowran
ge>
<product
dependent>
0/7 Available range for focuswindow.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0305d.
*-: Not supported.
lensconfiguration_sup
port 0,1 0/7 Indicate whether to support different
image library configuration files for
specific exchangeable lens.
freeze <boolean> 0/7 0: Non-support image freeze feature
1: Support image freeze feature
© 2020 VIVOTEK INC. All Right Reserved
201
NAME VALUE SECURITY
(get/set) DESCRIPTION
* We support this parameter when
the version number (httpversion) is
equal or greater than 0302a.
autotrack_support <boolean> 0/7 0: Non-support auto tracking feature
1: Support auto tracking feature
* We support this parameter when
the version number (httpversion) is
equal or greater than 0302a.
smartsensor_iristotalr
ange A list of iris value 0/7 Available total step for iris value.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0302a.
* Only available when
"capability_image_c<0~(n-1)>_sensor
type" is "smartsensor"
deinterlace_support <boolean> 0/7 Indicate whether to support
deinterlace function.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0308a.
deinterlace_mode spatial, blend 0/7 Spatical mode provides the best
image quality, while Blend mode
provides better image quality (than
not using the deinterlace function at
all).
* Only available when
capability_image_c<0~(n-1)>_deinterl
ace_support is 1
lens_alignment <boolean> 0/7 Indicate whether to support lens
alignment function.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0309b.
lens_alignmentlevel <positive integer> 0/7 The value indicate the support level of
alignment.
* Only available when
