Vivotek S Series IZ9361-EH 1080p Outdoor Network Bullet Camera with Heater - Manual (Page 39)

VIVOTEK
User's Manual - 39
Mute : Turn off the Mic volume on the local computer. The button becomes the Mic On button
after clicking the Mute button.
Full Screen : Click this button to switch to full screen mode. Press the “Esc” key to switch back to normal
mode.
■ The following window is displayed when the video mode is set to MJPEG:
Video Title : The video title can be configured. For more information, please refer to Media > Image on
page 63.
Time : Display the current time. For more information, please refer to Media > Image on page 63.
Title and Time : Video title and time can be stamped on the streaming video. For more information, please
refer to Media > Image on page 63.
Video Control Buttons : Depending on the Network Camera model and Network Camera configuration,
some buttons may not be available.
Snapshot : Click this button to capture and save still images. The captured images will be displayed
in a pop-up window. Right-click the image and choose Save Picture As to save it in JPEG (*.jpg) or BMP
(*.bmp) format.
Digital Zoom : Click and uncheck “Disable digital zoom” to enable the zoom operation. The navigation
screen indicates the part of the image being magnified. To control the zoom level, drag the slider bar. To
move to a different area you want to magnify, drag the navigation screen.
Start MP4 Recording : Click this button to record video clips in MP4 file format to your computer.
Press the Stop MP4 Recording button to end recording. When you exit the web browser, video
recording stops accordingly. To specify the storage destination and file name, please refer to MP4 Saving
Options on page 41 for details.
Full Screen : Click this button to switch to full screen mode. Press the “Esc” key to switch back to normal
mode.
Video 17:08:56 2015/07/25
Title and Time
2015/07/25 17:08:56
Time
Video (HTTP-V)
Video Title
Video Control Buttons
