Brother HLL9410CDN Enterprise Color Laser Printer User Manual
Page 166
> Configure Secure Function Lock 3.0 Using Web Based
Management
Configure Secure Function Lock 3.0 Using Web Based Management
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the
Login
field, and then click
Login
.
•
The default password to manage this machine’s settings is located on the back of the machine and
marked "
Pwd
".
4. Go to the navigation menu, and then click
Administrator
>
Restriction Management
or
User Restriction
Function
.
Start from
, if the navigation menu is not shown on the left side of the screen.
5. Select
Secure Function Lock
.
6. Click
Submit
.
7. Click the
Restricted Functions
menu.
8. In the
User List / Restricted Functions
field, type a group name or user name.
9. In the
and the other columns, select a check box to allow, or clear a check box to restrict, the function
listed.
10. To configure the maximum page count, select the
On
check box in the
Page Limits
column, and then type
the maximum number in the
Max. Pages
field.
11. Click
Submit
.
12. Click the
User List
menu.
13. In the
User List
field, type the user name.
14. In the
Password
field, type a password.
The number of characters you can set differs depending on the model.
15. To register the user's Card ID, type the card number in the
Card ID (NFC ID)
field (available only for certain
models).
16. Select
User List / Restricted Functions
from the drop-down list for each user.
17. Click
Submit
.
You can also change the user list lockout settings in the
Secure Function Lock
menu.
Related Information
•
161
