Configure the IPv6 route preference for the
switch
You can configure the default preference for the switch, which is a value in the range
from 1 to 255 and is independent of route metrics. Most routing protocols use a route
metric to determine the shortest path known to the protocol, independent of any other
protocol. The best route to a destination is automatically selected by determining the
route with the lowest preference value. If multiple routes to a destination exist, the
preference value is used to determine the preferred route. If a tie occurs, the route with
the best route metric is selected.
Configure the IPv6 route preference for the switch:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Log in to the main UI with a web
browser on page 27 and the subsections.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Routing > IPv6 > Advanced > Route Preference.
The Route Preference page displays.
6. In the Static field, specify the static route preference value for the switch
The range is from 1 to 255. The default value is 1.
7. In the OSPFv3 Intra field, specify the OSPFv3 intra route preference on the switch.
The default value is 110. The range is from 1 to 255.
8. In the OSPFv3 Inter field, specify the OSPFv3 inter route preference on the switch.
The default value is 110. The range is from 1 to 255.
9. In the OSPFv3 External field, specify the OSPFv3 external route preference on the
switch.
The default value is 110. The range is from 1 to 255.
10. Click the Apply button.
