To delete a static multicast route:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

If you do not know the IP address of the switch, see Log in to the main UI with a web
browser
on page 27 and the subsections.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.

The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Routing > IPv6 Multicast > Static Routes Configuration.

The Static Routes Configuration page displays.

6. Select the check box for the static route.

7. Click the Delete button.

Your settings are saved. The static route is deleted.

8. To save the settings to the running configuration, click the Save icon.

Main User Manual

583

Configure Multicast Routing

Fully Managed Switches M4350 Series Main User Manual
