The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Routing > IPv6 Multicast > MLD > MLD Groups.
The MLD Groups page displays.
6. To search for IGMP group entries by interface or group, select one of the following
options from the Search menu:
• Interface: Select Interface from the menu, specify the interface in unit/port format
(for example 0/8), and click the Go button.
If the entry exists, the entry is displayed as the first entry, followed by the remaining
entries.
• Group: Select Group from the menu, specify the multicast group IPv6 address,
and click the Go button.
If the entry exists, that entry with the matching group IPv6 address is displayed
as the first entry, followed by the remaining entries. An exact match is required.
7. To refresh the page, click the Refresh button.
The following table describes the view-only fields on the page.
Table 141. MLD groups information
Description Field
The interface on which MLD is enabled. Interface
The IP multicast group address. Group IP
The IP address of the source of the last membership report that was
received for the IP multicast group address on the interface. Last Reporter
The period elapsed since this entry was created. Up Time
The period remaining before this entry is aged out. Expiry Time
The source filter mode (Include, Exclude, or NA) for the group on the
interface. If the mode is NA, the field is blank. Filter Mode
The period remaining until the switch determines that no MLD version 1
members are attached to the interface. Version 1 Host Timer
