Adjusting the Camera
The picture quality of the camera can be set using
the [Camera Process] menu.
As the adjustments are shown on the screen, you
can adjust the values while checking the picture
quality on the camera.
0 [Color Space]
0 [Gamma]
0 [Detail]
0 [Master Black]
0 [Black Paint]
0 [Flare]
0 [V. Shading]
0 [Black Toe]
0 [Knee Level]
0 [Auto Knee Sensitivity]
0 [Auto Knee Peak Filter]
0 [White Clip]
0 [Chroma Clip]
0 [White Balance]
0 [Color Matrix]
0 [Color Gain]
0 [Reverse Picture]
0 [DNR]
Memo :
0 For details of the respective items, see the
[Camera Process] menu.
(
A
P116 [Camera Process Menu] )
Audio Recording
You can record audio from the four channels (CH1/
CH2/CH3/CH4) in synchronization with the video
images on this camera recorder.
Select from the options below to record the audio.
0 Microphone connected to [MIC IN] terminal
(XLR 5-pin)
0 Microphone or line input connected to the
[AUDIO INPUT1] terminal (XLR 3pin)
0 Microphone or line input connected to the
[AUDIO INPUT2] terminal (XLR 3pin)
.
PR AUDIO INPUT
DIS
Setting the Number of Recording
Channels
0 Set the number of recording channels in
[System]
B
[Record Set]
B
[Record Format]
B
[Audio].
Selecting Audio to Be Recorded in Each
Channel
Select the audio to be recorded in CH1/CH2/CH3/
CH4.
-
Switch
Setting
Connected Devices
CH1
CH3
FRONT 0 Audio input of
microphone 1 from
[MIC IN] terminal
REAR 0 Audio input from
[AUDIO INPUT1]
terminal
WIRELESS 0 Audio input of CH1
from the “UniSlot”
wireless receiver
CH2
CH4
FRONT 0 Audio input of
microphone 2 from
[MIC IN] terminal
REAR 0 Audio input from
[AUDIO INPUT2]
terminal
WIRELESS 0 Audio input of CH2 (or
CH1) from the “UniSlot”
wireless receiver
Adjusting the Camera Image
