QNAP TVS-472XT 4-Bay NAS Enclosure User Manual
Page 157
13. Click Next.
14. Select a LUN.
Important
The LUN must be thick and block-based, and must have a capacity of at least 154 GB. Mutual
CHAP must be disabled.
15. Click Next.
16. Optional: Enable CHAP authentication.
An initiator must authenticate with the target using the specified username and password. This
provides security, as iSCSI initiators do not require a NAS username or password.
• Username
• Length: 1 to 127 characters
• Valid characters: 0 to 9, a to z, A to Z, colon (:), period (.), hyphen (-)
• Password
• Length: 12 to 16 characters
• Valid characters: 0 to 9, a to z, A to Z, all special characters
17. Optional: Enable CRC checksums.
Initiators and targets communicate over TCP connections using iSCSI protocol data units (PDU). The
sending device can send a checksum with each PDU. The receiving device uses this checksum to verify
the integrity of the PDU, which is useful in unreliable network environments. There are two checksum
types, which can be enabled separately.
Checksum Type
Description
Data Digest
The checksum can be used to verify the data portion of the PDU.
Header Digest
The checksum can be used to verify the header portion of the
PDU.
18. Click Next.
19. Review the summary, and then click Next.
QTS creates a VJBOD disk using the LUN. The disk appears at Storage & Snapshots > Storage >
Disks/VJBOD .
20. Select a follow-up action.
Action
Description
Create New Storage Pool
Creates a storage pool using the VJBOD disk
Create New Static Volume
Creates a static volume using the VJBOD disk
Recover Existing Data
Restores a static volume or storage pool that was previously
created on the VJBOD disk
QTS 4.4.x User Guide
Storage & Snapshots
156
